SAlC Hongyan 6X4 30 ton Dump Truck
2024-10-07 09:54:11 Source：chusheng
Chassis configuration:
1.Engine: ltaly CURSOR
2.Transmission type: 8-speed gearbox
3.Wheelbase: /(mm)
4.Tyre: 12.00R20, 10+1 spare
5.Other:Flat proof, single sleeper, radio, air seat, A/C
| Product Name |
SAlC Hongyan 6X4 30 ton Dump Truck |
| Driving Type |
6x4 |
| Dump body Volume(cbm) |
18 |
| Rated payload weight(kg) |
30000 |
| Overall Dimension(mm) |
8500x2430x3400 |
| Dump body size(mm) |
5400X2300X1400 |
| Engine brand & model |
ltaly CURSOR |
| Engine type |
4 stroke,water-cooled, straight line 6 cylinders, diesel |
| Axle Quantity |
3 |
| Transmission Type |
8-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
12.00R20, 10+1 spare |
| Cab |
Flat proof, single sleeper, radio, air seat, A/C |
| Dump body material |
High strength manganese steel |
| Main configuration |
1.Side plate 6mm, floor plate 8mm 2. Front mounted hydraulic lifting cylinder. |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
SAlC Hongyan 6X4 30 ton Dump Truck
A dump truck, also known as atippertruck, refers to a vehicle that unloads goods on its own by hydraulic or mechanical lifting. Also known as a dump truck. It consists of components such as car chassis, hydraulic lifting mechanism, cargo compartment, and power take-off device.
The compartments of dump trucks are divided into two types: backward tilting and lateral tilting. The piston rod movement is controlled by the control system, and backward tilting is more common. Pushing the piston rod causes the compartment to tilt, while a few tilt in both directions.
Product parameters
