Dongfeng 40 Ton Dumper Truck
Chassis
brand dongfeng
Product
origin China, Hubei
Delivery time around 10 working days
Supply
capacity 1,500 units one year
In
engineering construction, dumper truck is often operated in conjunction with excavators,
loaders, belt conveyors, etc. dumper truck is mainly used for loading and
unloading soil, sand, and loose materials.
Dongfeng
dumper truck can automatically tip over to unload at a certain angle, dongfeng
40 ton dumper truck greatly saves unloading time and manpower, improves
production efficiency and reduces transportation costs.
| Product Name |
Dongfeng 40 Ton Dumper Truck |
| Driving Type |
8X4 |
| Dump body Volume(cbm) |
23 |
| Rated payload weight(kg) |
40000 |
| Overall Dimension(mm) |
9700x2490x3500 |
| Dump body size(mm) |
6700x2300x1500 |
| Engine brand & model |
DONGFENG Cummins or Yuchai power |
| Engine type |
4 stroke,water-cooled, straight line 6 cylinders, diesel |
| Axle Quantity |
4 |
| Transmission Type |
FAST 9 forwards,1 reverse gear, manul |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
11.00R20, 12+1 spare |
| Cab |
flat proof, single sleeper,radio, AC |
| Dump body material |
High strength manganese steel |
| Main configuration |
1.Side plate 6mm, floor plate 8mm(optional side 8mm ,floor 10mm). 2. Front lifting hydraulic cylinder |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng 40 Ton Dumper Truck
A tipper truck refers to a vehicle that unloads
goods on its own through hydraulic or mechanical lifting, also known as a dump
truck. It consists of components such as car chassis, hydraulic lifting
mechanism, cargo compartment, and power take-off device.
Dumper
truck is also called tipper truck, dump truck, Dongfeng 40 ton dumper truck is
mainly used to transport kinds of sand, sol. rock, ore etc material from 20 ton
to 40 ton.
Product
feature
Dongfeng
12 wheel dump truck
40
ton loading capacity
Dump
body made of China high strength manganese steel, strong and sturdy;
Factory
direct sale, mass production and fast delivery
Product parameters
