Dongfeng 4X4 Dump Truck
2024-10-07 09:54:11 Source：chusheng
Dongfeng 4X4 Dump Truck
Chassis brand Dongfeng
Product origin China, Hubei
Delivery time around 7 working days
Supply capacity 1,500 units one year
44 dump truck can meet loading and
unloading in bad road condition. Dongfeng 4X4 dump truck is mainly used for
loading and unloading soil, sandand loose materials in engineering and
construction field.
Compared to 4X2 dump truck, 4X4 dump truck
have more advantage. goodpassability, and wider adaptability. Dongfeng 4X4 dump
truck greatly saves unloading time and labor, shortens the transportation cycle,
improves production efficiency, and reduces transportation costs.
| Product Name |
Dongfeng 4X4 Dump Truck |
| Driving Type |
4X4 |
| Dump body Volume(cbm) |
4 |
| Rated payload weight(kg) |
5000 |
| Overall Dimension(mm) |
5800x2300x2800 |
| Dump body size(mm) |
3760x2200x600 |
| Engine brand & model |
DONGFENG CHAOYANG Or YUNNEI |
| Engine type |
4 stroke,water-cooled, straight line 4 cylinders, diesel |
| Axle Quantity |
2 |
| Transmission Type |
5 forwards,1 reverse gear, manual |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
7.00R10, 6+1 spare |
| Cab |
Flat proof, single row, radio, sound ,air conditioning and so on |
| Dump body material |
High strength manganese steel |
| Main configuration |
1. Side plate 3mm, floor plate 4mm. 2.Middle double hydraulic lifting cylinder |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng 4X4 Dump Truck
A dump truck refers to a vehicle that unloads
goods on its own through hydraulic or mechanical lifting. Also known as a dump
truck. It consists of components such as car chassis, hydraulic lifting
mechanism, cargo compartment, and power take-off device.
4x4 dump truck is also called all wheel
drive dump truck, can be used to transport kinds of sand. soil. rock, ore. etc
material in very bad road condition.
Product feature
Dongfeng 4x4 dump truck chassis
Dump box made of high strength manganese
steel. strong and sturdy;
5 ton payload capacity
Factory direct sale
Product parameters
