Dongfeng 6X4 Mud Dump Truck
2024-10-07 09:54:11 Source：chusheng
Dongfeng 6X4 Mud Dump Truck
Chassis brand dongfeng
Product origin China, Hubei
Delivery time around 10 working days
Supply capacity 1500 units one year
Sludge dump truck refers to a vehicle that unloads goods on its own through hydraulic or mechanical lifting. Also known as a dump truck. It consists of components such as car chassis, hydraulic lifting mechanism, cargo compartment, and power take-off device. In civil engineering, dump trucks are often used in conjunction with construction machinery such as excavators, loaders, and belt conveyors to form loading, transportation, and unloading production lines for the loading, unloading, and transportation of soil, sand, and loose materials.
| Product Name |
Dongfeng 6X4 Mud Dump Truck |
| Driving Type |
6X4 |
| Dump body Volume(cbm) |
20 |
| Rated payload weight(kg) |
25000 |
| Overall Dimension(mm) |
9050,9300X2550X3250 |
| Dump body size(mm) |
6300,6500X2200X1500 |
| Engine brand & model |
YCS06245-60A, Yuchai |
| Engine type |
4 stroke,water-cooled, straight line 6 cylinders, diesel |
| Axle Quantity |
3 |
| Transmission Type |
FAST 8 forwards, manual |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
11.00R20, 10+1 spare |
| Cab |
Air conditioning, airbag seats, multifunctional steering wheel |
| Dump body material |
carbon steel |
| Main configuration |
1. Side plate 4mm, floor plate 5mm. 2.Front hydraulic cylinder, rear hydraulic opening, top hydraulic opening |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng 6X4 Mud Dump Truck
Mud dump truck refers to a vehicle that unloads goods by hydraulic or mechanical lifting, also known as a dump truck. Mud dump trucks are used for urban sludge removal and the loading, unloading, and transportation of various scattered materials. They have a rated load capacity of 5 tons, 6 tons, 8 tons, 10 tons, 12 tons, 15 tons, 18 tons, and 20 tons. The cargo body is controlled by hydraulic tilting and the rear door can be automatically opened and locked The self dumping mechanism and cargo compartment rear cover of the entire vehicle can facilitate the smooth dumping of sludge and effectively reduce pollution to the urban environment and minimize material loss during transportation. The hydraulic system is easy to operate and flexible.
Product feature
1-Dongfeng 10 wheel dump truck with Guangxi Yuchai engine
2-Dump box made of China carbon steel, strong and sturdy;
3-25 ton loading capacity
4-Factory direct sale
Product parameters
