Saic Hongyan 6x4 18T one tow two wrecker truck
2024-10-07 09:54:11 Source：chusheng
Chassis configuration:
① Driver's cab: Jiehu flat top standard length driver's cab, 2300mm ultra wide body, with single sleeper
② Engine: YCK08-350-60, Yuchai 8 liters 350 horsepower, economical and fuel-efficient
③ Transmission: Fast 12 speed gearbox with overdrive and original power take-off
④ Front and rear axles: front axle weighing 7.5 tons, rear axle weighing 16 tons, heavy-duty dual stage wheel reduction axle, speed ratio 4.8
⑤ Tires: Front tire 385/65R22.5, rear tire 12.00R20 18PR
⑥ Frame: 980-865/305x80 (8+8+4) three-layer super strong frame
⑦ Other configurations: 165Ah battery, remote control central locking, electric cab flip, mechanical shock absorber suspension, electric doors and windows, 10 inch central control screen (with reverse image)
| Product Name |
Saic Hongyan 6x4 18T one tow two wrecker truck |
| Driving Type |
6x4 |
| Gross vehicle weight(Kg) |
35000(Kg) |
| Curb weight(Kg) |
18800,18200,17600(Kg) |
| Rated weight(kg) |
/ |
| Wheelbase(mm) |
4800+1400,4600+1400,4400+1400,6000+1400(mm) |
| Overall Dimension(mm) |
12360,11160×2550,2500×3150,3100,3050(mm) |
| Engine |
As follows |
| Engine brand & model |
YCS06270-60A, Yuchai 350hp |
| Axle Quantity |
3 |
| Transmission Type |
12-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
Front tire 385/65R22.5, rear tire 12.00R20 18PR, 10+1 spare |
| Cab |
Jiehu flat top standard length cab, 2300mm ultra wide body, with single sleeper |
| Platform |
8mm thick patterned plate (without holes), flat plate length of 10 meters (8.7 meters+1.3 meters hydraulic flip) |
| Crane specification |
no crane |
| Standard configuration |
/ |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Saic Hongyan 6x4 18T one tow two wrecker truck
A tow truck (also called
a wrecker, a breakdown truck, recovery vehicle or
a breakdown lorry) is a truck used to move disabled,improperly parked, impounded, or otherwise indisposed motor vehicles. This
may involve recovering a vehicle damaged in an accident, returning one to a drivable surface in a mishap or inclement weather,
or towing or transporting one via flatbed to a repair
shop or other location.
This vehicle is mainly used for road block removal , and its main
specialized devices are flat plates, supporting arms, winches, steel wire
ropes, and oil cylinders.
Product parameters
