Shacman Xuande X6 4X2 wrecker truck with crane
2024-10-07 09:54:11 Source：chusheng
Chassis configuration:
5600mm wheelbase, seat: driver airbag shock-absorbing seat, cab color: Jin Jun Huang (solid paint), engine model: YCS06270-60, transmission model: 9JS119TA, reservoir: 135Ah/maintenance free, front axle model: 5t, rear axle model: 13t single-stage/4.875, tire grid: 10.00R20/18PR, fuel tank/gas cylinder specification: 200L/aluminum, front leaf spring model: 9, rear leaf spring number: 10+6, 861 * 250/8+6 double-layer, other configurations: with front protection, spare tire, verified locking function, sunshade, 4.3-inch color LCD screen combination instrument.
| Product Name |
Shacman Xuande X6 4X2 wrecker truck with crane |
| Driving Type |
4X2 |
| Gross vehicle weight(Kg) |
18000(Kg) |
| Curb weight(Kg) |
11550,11000(Kg) |
| Rated weight(kg) |
/ |
| Cab |
Shacman Xuande X6 cab |
| Engine brand & model |
YCS06270-60, Yuchai 270 horsepower |
| Wheelbase(mm) |
5600(mm) |
| Axle Quantity |
2 |
| Transmission Type |
9-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Tire Spec. & size |
10.00R20/18PR, 6+1 spare |
| Overall Dimension(mm) |
10550,10400,10195,10045,10030,9880,9865,9715,9700,9550,9205,9055,9040,8890,8875,8725,8380,8230,7965,7815×2550×2950,2860(mm) |
| Crane specification |
XCMG M-series 8-ton four section straight arm crane! |
| Standard configuration |
10 ton loading, 8-ton winch, 6mm thick patterned plate |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Shacman Xuande X6 4X2 wrecker truck with crane
A wrecker truck with crane is a specialized vehicle that combines the functions of a clearing vehicle and an on-board crane. It is mainly used for tasks such as road malfunction vehicles, urban illegal vehicles, and emergency rescue. This type of vehicle has added a lifting function on the basis of ordinary clearing vehicles, which can cope with more complex situations during rescue, such as the accident vehicle leaving the roadbed, and complete rescue tasks through the lifting function.
The main device consists of a lifting platform, winch, crane, and hydraulic device
Installation configuration:
10 ton top, 8-ton winch, 6mm thick patterned plate, imported hydraulic components, HZL oil cylinder, 10 ton three section rear support arm, sinking process, total length of the plate is 7.2 meters, with a 1-meter hydraulic flip tail plate at the tail, a 16mm steel plate frame with tie holes below, a pair of support sockets, two pairs of towing forks, a set of tire holding devices, tie straps, auxiliary trolley, two auxiliary air pipes, alarm lights, hand washing water tank, double chain hook. Reinforce the tail of the main beam and equip it with XCMG M-series 8-ton four section straight arm crane!
Product parameters
