Saic Hongyan Genpaw 4x2 8T one tow two wrecker truck
2024-10-07 09:54:11 Source：chusheng
Saic Hongyan Genpaw 4x2 8T one tow two wrecker truck
Chassis configuration:
1. Engine: YCS06270-60, Yuchai 270ph
2.Transmission type: 8-speed with original power take-off
3.Tyre: 10.00R2018PR, 6 with a spare
4.Wheelbase: 7150mm
5 Other: Remote control central locking, automatic heating and cooling air conditioning, metal bumper, manual cab flipping, luxury manual rearview mirror
Installation configuration:
8-ton sunken flat plate, 8-ton sunken winch, 35 meter steel wire rope, plate length of 11.6 meters (9.6 meters+2-meter telescopic plate at the tail), width of 2.55 meters, using 6mm thick patterned plate, double 10mm thick sliding groove (double layer height 166mm), double auxiliary beams, 5-ton 2-section rear support arm, double-sided linkage operation, naval hydraulic oil cylinder, one pair of LED working lights, one toolbox, and the rest as standard.
| Product Name |
Saic Hongyan Genpaw 4x2 8T one tow two wrecker truck |
| Driving Type |
4×2 |
| Weight /Classification |
As follows |
| Type |
one tow two wrecker truck |
| Lift weight(kg) |
4370-5525 |
| Dimensions |
As follows |
| Wheelbase(mm) |
7150 |
| Overall Dimension(mm) |
12020,10670,10870,10470,11170×2550,2500×3850,3800,3750,3700,3650 |
| Engine |
As follows |
| Engine brand & model |
YCS06270-60, Yuchai 270hp |
| Displacement(L)/Power(kw) |
6.23L/199KW |
| Chassis |
As follows |
| Axle Quantity |
2 |
| Transmission Type |
8-speed with original power take-off |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
10.00R2018PR, 6 with a spare |
| Cab |
Hongyan Genpaw H6 cab |
| Standard configuration |
135Ah battery, remote control central locking, automatic heating and cooling air conditioning, metal bumper, electric cab flip, luxury manual rearview mirror. |
| Air conditioning |
Have |
| Performance parameter |
As follows |
| Platform |
Using high-quality patterned board with a thickness of 6MM, the flat plate is 5.6 meters or 5.8 meters long |
| Crane specification |
/ |
| Standard configuration |
/ |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Saic Hongyan Genpaw 4x2 8T one tow two wrecker truck
A tow truck (also called
a wrecker, a breakdown truck, recovery vehicle or
a breakdown lorry) is a truck used to move disabled,improperly parked, impounded, or otherwise indisposed motor vehicles. This
may involve recovering a vehicle damaged in an accident, returning one to a drivable surface in a mishap or inclement weather,
or towing or transporting one via flatbed to a repair
shop or other location.
This vehicle is mainly used for road block removal , and its main
specialized devices are flat plates, supporting arms, winches, steel wire
ropes, and oil cylinders.
Product parameters
