Dongfeng K7 9m³ water sprinkling truck
2024-10-09 15:48:19 Source：chusheng
Dongfeng K7 9m³ water sprinkling truck
Chassis configuration:
1. Engine: National VI Yuchai 165 horsepower
2.Transmission type: Wanliyang 6-speed gearbox
3.Tyre:9.00R20 steel wire tire
4.Wheelbase:3800mm
5 Other:air brake, electric glass, central locking multifunction steering wheel, driving recorder,
Entertainment display screen, sunshade.
Installation configuration:1.The tank body is about 9 cbm.2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.4. Punching platform (with enhanced load-bearing capacity), customized bolt buckle 5 for the rear cover of the gun barrel, front spray, rear punch, rear wine, side spray, and engineering specific ball valves for the green anti-aircraft gun switch
5. 50 large diameter copper ball valve
6. New bearing water cannon, more durable
7. 40-50 type water pump
8. Anti corrosion flange gasket
9. Aluminum spill, not easy to explode
| Product Name |
Dongfeng K7 9m³ water sprinkling truck |
| Driving type |
4X2 |
| Engine Model |
YCY30165-60 |
| Engine horsepower |
Yuchai 165hp |
| Engine displacement |
2.97L |
| Gearbox |
Wanliyang 6-speed gearbox |
| Tire specification |
9.00R20 steel wire tire, 6+1 spare |
| Wheel base (mm) |
3800 |
| Gross vehicle weight(Kg) |
11995 |
| Curb weight(Kg) |
4720 |
| Rated weight(Kg) |
7080 |
| Vehicle dimensions (mm) |
7230x2250,2350x2700 |
| Tank volume(cbm) |
9 |
| Fuel type |
diesel |
| Emission standard |
Euro 6 (option:Euro3/4/5) |
| Water pump model |
40/50 |
| Tank material |
Q235 carbon steel |
| Additional configuration |
Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng K7 9m³ water sprinkling truck
water sprinkling truck, also known as water truck,
multifunctional sprinkler truck, or garden greening sprinkler truck. Sprinkler
trucks are suitable for various road surface cleaning, tree, green belt, lawn
greening, road, factory and mining enterprise construction, and high-altitude
building cleaning. Sprinklers can also be used as water transport vehicles, and
the most common types of vehicles include sanitation sprinklers,
multifunctional sprinklers, and green sprinklers.
