SHACMAN X9 12m³ water sprinkling truck

SHACMAN X9 12m³ water sprinkling truck

2024-10-09 15:48:19 Source：chusheng

Chassis configuration:
1. Engine: Yunnei 180hp,Yuchai 170hp

2.Transmission type: 8 forward gears and 1 reverse gear

3.Tyre:9.00R20 steel wire tire

4.Wheelbase:4100mm

5 Other: Air brake, multifunctional steering wheel, original air conditioning, electric doors and windows, central locking system, driving recorder, sunshade..
Installation configuration:
1.The tank body is about 12 cbm.
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

Product Name

SHACMAN X9 12m³ water sprinkling truck

Engine Model

D40TCIF1/YCY30170-61

Engine horsepower

Ynnei 180hp,Yuchai 170hp

Engine displacement

4.05L,2.97L

Gearbox

8 forward gears and 1 reverse gear

Tire specification

9.00R20 steel wire tire

Wheel base (mm)

4100

Gross vehicle weight(Kg)

16000

Curb weight(Kg)

6480,6300

Rated weight(Kg)

9390,9325,9570,9505

Vehicle dimensions (mm)

7420,7320,7220×2550,2500×3100,2960

Tank volume(cbm)

Fuel type

diesel

Emission standard

Euro 6 (option:Euro3/4/5)

Water pump model

60/90

Tank material

Q235 carbon steel

Additional configuration

Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light

Notice

The above information is for reference only, and vehicles can be customized depending on your requirements.

SHACMAN X9 12m³ water sprinkling truck

Water truck, also known as sprinkler truck, multifunctional sprinkler truck, or garden greening sprinkler truck. Sprinkler trucks are suitable for various road surface cleaning, tree, green belt, lawn greening, road, factory and mining enterprise construction, and high-altitude building cleaning. Sprinklers can also be used as water transport vehicles, and the most common types of vehicles include sanitation sprinklers, multifunctional sprinklers, and green sprinklers.
