Dongfeng D6 4x2 water truck

Dongfeng D6 4x2 water truck

2024-10-09 15:48:19 Source：chusheng

Chassis configuration:
1. Engine: Quanchai 115HP/Quanchai 136 HP

2.Transmission type: 6-speed transmission

3.Tyre:7.00 steel tires

4.Wheelbase:3308mm

5 other: a gas brake, electric glass, a central locking multifunction steering wheel, a driving recorder, an entertainment display screen, and a sunshade.
Installation configuration:
1.The tank body is about 7cbm.
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

Product Name

Dongfeng D6 4x2 water truck

Engine Model

Q23-136E60

Engine horsepower

136hp/100KW

Engine displacement

2.3L

Gearbox

6 forward gears and 1 reverse gear

Wheel base (mm)

3308

Gross vehicle weight(Kg)

4495

Tire specification

7.00 steel wire tire

Curb weight(Kg)

3865

Rated weight(Kg)

500

Vehicle dimensions (mm)

5995x2030x3000

Tank volume(cbm)

Fuel type

diesel

Emission standard

Euro 6 (option:Euro3/4/5)

Water pump model

40/50

Tank material

Q235 carbon steel

Additional configuration

Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light

Notice

The above information is for reference only, and vehicles can be customized depending on your requirements.

Dongfeng D6 4x2 water truck

Water truck, also known as sprinkler truck, multifunctional sprinkler truck, or garden greening sprinkler truck. Sprinkler trucks are suitable for various road surface cleaning, tree, green belt, lawn greening, road, factory and mining enterprise construction, and high-altitude building cleaning. Sprinklers can also be used as water transport vehicles, and the most common types of vehicles include sanitation sprinklers, multifunctional sprinklers, and green sprinklers.
