Dongfeng F7 4x2 9m³ water tank truck

Dongfeng F7 4x2 9m³ water tank truck

2024-10-09 15:48:19 Source：chusheng

Chassis configuration:
1. Engine: Yunnei 150hp

2.Transmission type: 6-speed transmission

3.Tyre:8.25R20 steel wire tire

4.Wheelbase:3800mm

5 other: Air brake, multifunctional steering wheel, original air conditioning, electric doors and windows, central locking system, driving recorder, sunshade..
Installation configuration:
1.The tank body is about 9cbm.
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

Product Name

Dongfeng F7 4x2 9m³ water tank truck

Engine Model

D25TCIF1

Engine horsepower

Yunnei 150hp/110KW

Engine displacement

2.49L

Gearbox

6 forward gears and 1 reverse gear

Tire specification

8.25R20 steel wire tire

Wheel base (mm)

3800

Gross vehicle weight(Kg)

11995

Curb weight(Kg)

4720

Rated weight(Kg)

7080

Vehicle dimensions (mm)

7230,7810×2250,2350×2700,2850

Tank volume(cbm)

Fuel type

diesel

Emission standard

Euro 6 (option:Euro3/4/5)

Water pump model

40-50

Tank material

Q235 carbon steel

Additional configuration

Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light

Notice

The above information is for reference only, and vehicles can be customized depending on your requirements.

Dongfeng F7 4x2 9m³ water tank truck

Water truck, also known as sprinkler truck, multifunctional sprinkler truck, or garden greening sprinkler truck. Sprinkler trucks are suitable for various road surface cleaning, tree, green belt, lawn greening, road, factory and mining enterprise construction, and high-altitude building cleaning. Sprinklers can also be used as water transport vehicles, and the most common types of vehicles include sanitation sprinklers, multifunctional sprinklers, and green sprinklers.
