Dongfeng 10 Ton Dump Truck
Chassis brand Dongfeng
Product origin China, Hubei
Delivery time around 10 working days
Supply capacity 1500 units one year
10 ton dump truck is mainly used for loading and unloading soil, sand, ore and loose materials. Dongfeng 10 ton dump truck belongs to medium duty dump truck, is suitable for small-scale sand field.
10 ton dump truck can automatically backward tip over to unload at a certain angle, greatly saves unloading time and labor, ,improves production efficiency, and reduces transportation cost
| Product Name | Dongfeng 10 Ton Dump Truck |
| Driving Type | 4X2 |
| Dump body Volume(cbm) | 11 |
| Rated payload weight(kg) | 10000-15000 |
| Overall Dimension(mm) | 7200x2300x3200 |
| Dump body size(mm) | 4500x2200x1100 |
| Engine brand & model | DONGFENG Cummins & B190 33 |
| Engine type | 4 stroke,water-cooled, straight line 6 cylinders, diesel |
| Axle Quantity | 2 |
| Transmission Type | FAST 8 forwards,1 reverse gear, manual |
| Steering Type | LHD or RHD with power steering |
| Brake system | Air brake |
| Tire Spec. & size | 10.00R20, 6+1 spare |
| Cab | Flat proof, single sleeper,radio,AC |
| Dump body material | High strength manganese steel |
| Main configuration | 1.Side plate 4mm, floor plate 5mm 2. Middle double hydraulic lifting cylinder. |
| Notice | The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng 10 Ton Dump Truck
10 ton dump truck is also called 10 ton tipper truck, 10 ton dumper truck, is used to transport kinds of sand, soi, rock, ore, etc material
Product feature
Dongfeng Cummins engine 190hp
Dump box adopt China high strength manganese steel. strong and sturdy;
10 ton loading capacity
Factory direct sale
Product parameters
