FAW Jiefang 3m³ sewage suction truck
2024-10-07 09:54:11 Source：chusheng
FAW Jiefang 3m³ sewage suction truck
Chassis configuration:
Jiefagn V5 cab, new interior design. Yunnei 102 horsepower, D20TCIF14 National VI engine, 5-speed gearbox, 2400mm wheelbase, oil brake, spring steel plate 4/5+2, 6.00-15 10PR tires, ABS, electric shut-off, 24V battery, electrically adjustable radio+MP3.
| Product Name |
FAW Jiefang 3m³ sewage suction truck |
| Driving Type |
4X2 |
| Gross vehicle weight(Kg) |
4495(Kg) |
| Curb weight(Kg) |
2650(Kg) |
| Rated weight(kg) |
1715(Kg) |
| Wheelbase(mm) |
2400(mm) |
| Overall Dimension(mm) |
5050×1880,1950×2250,2380,2480(mm) |
| Tank volume(cbm) |
2.6m³ -3m³ |
| Engine brand & model |
D20TCIF14, Yunnei 102 horsepower |
| Displacement(L)/Power(kw) |
1.99L |
| Axle Quantity |
2 |
| Transmission Type |
5-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
6.00-15LT 10PR, 6+1 spare |
| Cab |
Jiefang V5 cab |
| Tank material |
8mm carbon steel |
| Standard configuration |
Oil water separator, water gas separator, hydraulic dumping device, special vacuum suction bump, volume pressure gauge,suction pipe, gravity valve, vacuum tank, connected vessels (fecal window), full-automatic anti overflow valve, hydraulic kit. |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
FAW Jiefang 3m³ sewage suction truck
Sewage suction truck, also called sewage tanker
truck, sewage truck, sewage suction tanker truck,vacuum sewage suction
truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc
.
Introduction
Suction sewage truck is a new type of environmental sanitation vehicle
that collects, transfers, cleans, and transports sludge and sewage to avoid
secondary pollution. The suction truck can self suction and discharge, with
fast working speed, large capacity, and convenient transportation. It is
suitable for collecting and transporting liquid substances such as feces, mud,
and crude oil. The suction truck adopts a domestically advanced vacuum pump
with high suction force and long suction distance, which is particularly
suitable for the suction, transportation, and discharge of sediment in sewers,
especially for large objects such as sewage mud, sludge, stones, bricks, etc.Product parameters
