Dongfeng D9 sewage tanker truck,10m³-12m³ suction cleaning truck
2024-10-07 09:54:11 Source：chusheng
Dongfeng D9 sewage tanker truck,10m³-12m³ suction cleaning truck
The suction truck is mainly used for cleaning urban sewers, sediment in
pipelines, dredging dead corners and mud ditches, as well as cleaning
industrial discharge pipelines, walls, etc. It can also be used for watering,
transporting water, and flushing highways. It can be used for firefighting in
emergency situations.
| Product Name |
Dongfeng D9 sewage tanker truck,10m³-12m³ suction cleaning truck |
| Driving Type |
4x2 |
| Weight /Volume |
|
| Tank volume(cbm) |
10m³-12m³ |
| Rated payload weight(kg) |
8000,8065,8490,8555,8855,8920 |
| Dimensions |
|
| Wheelbase(mm) |
3600,3950,4500,4700,5000,5300,5600,3600 |
| Overall Dimension(mm) |
7200,7900,8100×2500×3300,3400 |
| Engine |
|
| Engine brand & model |
Commins, B6.2NS6B210 |
| Displacement(L)/Power(kw) |
6.2L/154KW |
| Chassis |
|
| Axle Quantity |
3 |
| Transmission Type |
8 forward gears and 1 reverse gear |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
295/80R22.5 ,10 with a spare |
| Cab |
|
| Standard configuration |
D9 series cab |
| Air conditioning |
YES |
| Performance parameter |
|
| Garbage container material |
high-quality carbon steel |
| Standard configuration |
Oil water separator, water gas separator, hydraulic dumping device, special vacuum suction bump, volume pressure gauge,suction pipe, gravity valve, vacuum tank, connected vessels (fecal window), full-automatic anti overflow valve, hydraulic kit. |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng D9 sewage tanker truck,10m³-12m³ suction cleaning truck
Sewage suction truck, also called sewage tanker
truck, sewage truck, sewage suction tanker truck,vacuum sewage suction
truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc
.
Introduction
Suction sewage truck is a new type of environmental sanitation vehicle
that collects, transfers, cleans, and transports sludge and sewage to avoid
secondary pollution. The suction truck can self suction and discharge, with
fast working speed, large capacity, and convenient transportation. It is
suitable for collecting and transporting liquid substances such as feces, mud,
and crude oil. The suction truck adopts a domestically advanced vacuum pump
with high suction force and long suction distance, which is particularly
suitable for the suction, transportation, and discharge of sediment in sewers,
especially for large objects such as sewage mud, sludge, stones, bricks, etc.Product parameters
