Dongfeng 6X4 sewage suction tanker truck, 22m³ sewage suction truck
2024-10-07 09:54:11 Source：chusheng
Dongfeng 6X4 sewage suction tanker truck, 22m³ sewage suction truck
Chassis configuration:
1. Adopting Dongfeng's original Tianlong rear eight wheel chassis, Cummins 290 horsepower engine, 4350+1350 wheelbase, 9-speed gearbox, original air conditioning, ABS, airbag seats, electric glass, central locking system, electric front folding luxury cab, brand new humanized interior, 11.00 original steel wire tires, and others as standard from Dongfeng's factory.
Installation configuration:
1. Overall dimensions of the vehicle: 9850 * 2550 * 2850. Tank size (straight section length * diameter): 5400 * 2200, tank volume is approximately 22 cubic meters. Suggested storage: 5 cubic meters of clean water, and the rest should be used as sewage tanks. The tank body is made of 8mm national standard carbon steel plate, and 8mm heads are used for separating the clean water and sewage tanks. There is a water tank mouth on the top of the clean water tank, and a cement tank mouth on the top of the dirty water tank.
| Product Name |
Dongfeng 6X4 sewage suction tanker truck, 22m³ sewage suction truck |
| Driving Type |
6x4 |
| Weight /Volume |
|
| Tank volume(cbm) |
22m³ |
| Rated payload weight(kg) |
/ |
| Dimensions |
|
| Wheelbase(mm) |
4350+1350 |
| Overall Dimension(mm) |
9850X2550X2850 |
| Engine |
|
| Engine brand & model |
Chaochai, YCY30165-60 |
| Displacement(L)/Power(kw) |
2.97L/121KW |
| Chassis |
|
| Axle Quantity |
3 |
| Transmission Type |
6 forward gears and 1 reverse gear |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
245/70R19.5,8.25R20, 6 with a spare |
| Cab |
|
| Standard configuration |
D7 series cab |
| Air conditioning |
YES |
| Performance parameter |
|
| Garbage container material |
high-quality carbon steel |
| Standard configuration |
Oil water separator, water gas separator, hydraulic dumping device, special vacuum suction bump, volume pressure gauge,suction pipe, gravity valve, vacuum tank, connected vessels (fecal window), full-automatic anti overflow valve, hydraulic kit. |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng 6X4 sewage suction tanker truck, 22m³ sewage suction truck
Sewage suction truck, also called sewage tanker
truck, sewage truck, sewage suction tanker truck,vacuum sewage suction
truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc
.
Introduction
Suction sewage truck is a new type of environmental sanitation vehicle
that collects, transfers, cleans, and transports sludge and sewage to avoid
secondary pollution. The suction truck can self suction and discharge, with
fast working speed, large capacity, and convenient transportation. It is
suitable for collecting and transporting liquid substances such as feces, mud,
and crude oil. The suction truck adopts a domestically advanced vacuum pump
with high suction force and long suction distance, which is particularly
suitable for the suction, transportation, and discharge of sediment in sewers,
especially for large objects such as sewage mud, sludge, stones, bricks, etc.Product parameters
