Dongfeng Tuyi 4X2 fecal suction truck
2024-10-07 09:54:11 Source：chusheng
Chassis configuration:2.5-ton Dongfeng Tuyi suction truck, chassis adopts Dongfeng Tuyi chassis, cab 1650/single row, Quanchai 95 horsepower engine (Q23-95E60), 5-speed gearbox, 185R14 vacuum tires, rear dual wheels, front and rear axles 1.5/3. Standard features include power steering, front wheel brake, central door lock, electric doors and windows, cruise control, Bluetooth phone, LED daytime running lights, ABS， air conditioner.
Upper configuration:Tank capacity of 2.5 cubic meters, Yifeng oil circulation vacuum pump, with a manure viewing window, one self flow port, hand washing device, 1 suction hose of 8 meters, with oil-water separator, vacuum pressure gauge, anti overflow valve, (suction truck with suspension rod seat, 1 60 suction pipe)
| Product Name |
Dongfeng Tuyi 4X2 fecal suction truck |
| Driving Type |
4X2 |
| Gross vehicle weight(Kg) |
4495(Kg) |
| Curb weight(Kg) |
2485(Kg) |
| Rated weight(kg) |
1880(Kg) |
| Wheelbase(mm) |
2800 (mm) |
| Overall Dimension(mm) |
5360×1800×1976(mm) |
| Tank volume(cbm) |
2.46m³ |
| Engine brand & model |
Q23-95E60, Quanchai 95hp |
| Axle Quantity |
2 |
| Transmission Type |
5-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Tire Spec. & size |
6.00R15 steel wire tire, 6+1 spare |
| Cab |
Dongfeng Tuyi cab |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng Tuyi 4X2 fecal suction truck
A fecal suction truck is a sanitation vehicle specifically designed for cleaning environments such as septic tanks, sewage ditches, and sewers. It belongs to the specialized vehicle sanitation vehicle series, mainly used for collecting, transferring, and cleaning transportation sludge, sewage, and feces to avoid secondary pollution. Suction trucks play an important role in urban hygiene and environmental protection, and are known as the "guardians of urban hygiene".
Product parameters
