Shacman Delong 4X2 suction sewage truck
2024-10-07 09:54:11 Source：chusheng
Shacman Delong 4X2 suction sewage truck
Chassis configuration
1.Engine:WP2.5NQ170E62, Weichai 170hp
2.Transmission type: FAST 6-speed gearbox
3.Tyre: 7.00R16LT 8PR, 6+1 spare
4.Wheelbase: 3300(mm)
5 Other: Equipped with power take-off switch, air conditioning, maintenance free battery, air brake, shut-off brake, luxurious fabric seats, central locking+electric doors and windows+remote keyUpper configuration:
The sewage tank is 4 cubic meters and the clean water tank is 2 cubic meters, with water and sewage interconnection. It is made of high-quality steel plates from Wugang, with a wall thickness of 6mm and a clean water tank thickness of 4mm. It is equipped with a 215 flow high-pressure pump and a filtering device,
| Product Name |
Shacman Delong 4X2 suction sewage truck |
| Driving Type |
4X2 |
| Gross vehicle weight(Kg) |
4495(Kg) |
| Curb weight(Kg) |
2805(Kg) |
| Rated weight(kg) |
1560,1495(Kg) |
| Wheelbase(mm) |
3300(mm) |
| Overall Dimension(mm) |
5995×2090×2750(mm) |
| Tank volume(cbm) |
6m³ (2m³ clear water tanks+4 m³ sewage tanks） |
| Engine brand & model |
WP2.5NQ170E62, Weichai 170hp |
| Displacement(L)/Power(kw) |
2.49L/125W |
| Axle Quantity |
2 |
| Transmission Type |
FAST 6-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
7.00R16LT 8PR, 6+1 spare |
| Cab |
Shacman Delong cab. Equipped with air conditioning, luxurious fabric seats, central locking system+electric doors and windows+remote key |
| Garbage container material |
Made of high-quality steel plates from WISCO |
| Standard configuration |
Oil water separator, water gas separator, hydraulic dumping device, special vacuum suction bump, volume pressure gauge,suction pipe, gravity valve, vacuum tank, connected vessels (fecal window), full-automatic anti overflow valve, hydraulic kit. |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Shacman Delong 4X2 suction sewage truck
Sewage suction truck, also called sewage tanker
truck, sewage truck, sewage suction tanker truck,vacuum sewage suction
truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc
.
Introduction
Suction sewage truck is a new type of environmental sanitation vehicle
that collects, transfers, cleans, and transports sludge and sewage to avoid
secondary pollution. The suction truck can self suction and discharge, with
fast working speed, large capacity, and convenient transportation. It is
suitable for collecting and transporting liquid substances such as feces, mud,
and crude oil. The suction truck adopts a domestically advanced vacuum pump
with high suction force and long suction distance, which is particularly
suitable for the suction, transportation, and discharge of sediment in sewers,
especially for large objects such as sewage mud, sludge, stones, bricks, etc.Product parameters
