Dongfeng Huashen 4X2 electric obstacle clearing vehicle
2024-10-07 09:54:11 Source：chusheng
Dongfeng Huashen 4X2 electric obstacle clearing vehicle
Chassis configuration: Dongfeng Huashen electric chassis, multi in one motor control, Ningde Times 77 degree electricity, electronic paddle shifters, straight through beam, front axle 2.2 tons/rear axle 3.5 tons, 650 vacuum steel wire tires, aluminum alloy steel rings, LCD instrument panel, with central control door lock, electric doors and windows, original air conditioning, etc
Wheelbase: 3300 wheelbase, 153 horsepower
Speed: 90KM/hour Range: 200 kilometers. Real situation of heavy vehicles. Uniform speed of around 80 yards per hour in the city
Upper configuration: The flat panel adopts a 5MM thick patterned integrated board, a one to two type, a 3-ton rear support arm, double-sided linkage operation device, 2 rear work lights, 1 40KN hydraulic winch (21 meter steel wire rope), toolbox, equipped with 2 small cars, 1 pair of L-shaped tire racks, 4 binding straps, and the rest are made according to the company's normal standards. Color: Depending on the chassis color
Top configuration: Lightweight top, 2-ton top, 4-ton winch, 21 meter steel wire rope, board length of 5.3 meters and width of 2.3 meters, double-sided linkage operation, four binding straps, chassis certificate, vehicle certificate, warranty manual. (Note: The upper door needs to be removed, the tailboard needs to be installed, and the protective measures need to be taken after installation.) Technical parameters: subject to the actual weight of the vehicle. The total weight is 4495kg.
| Product Name |
Dongfeng Huashen 4X2 electric obstacle clearing vehicle |
| Driving Type |
4X2 |
| Gross vehicle weight(Kg) |
4495(Kg) |
| Curb weight(Kg) |
2865,2800(Kg) |
| Rated weight(kg) |
1500(Kg) |
| Cab |
Dongfeng Huashen cab,LCD instrument panel with central control door lock, electric doors and windows, original air conditioning, etc |
| Engine brand & model |
TZ228XS-HSM1151 |
| Displacement(L)/Power(kw) |
115kw |
| Wheelbase(mm) |
3300mm |
| Axle Quantity |
2 |
| Transmission Type |
Electronic paddle shifters |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
/ |
| Tire Spec. & size |
650 vacuum steel wire tire, 6+1 spare |
| Overall Dimension(mm) |
5998×2300×2380(mm) |
| Platform |
The tablet adopts a 5MM thick patterned integrated board |
| Crane specification |
without crane |
| Standard configuration |
/ |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng Huashen 4X2 electric obstacle clearing vehicle
An obstacle clearing vehicle (also called
a wrecker, a breakdown truck, recovery vehicle or
a breakdown lorry) is a vehicle used to move disabled,improperly parked, impounded, or otherwise indisposed motor vehicles. This
may involve recovering a vehicle damaged in an accident, returning one to a drivable surface in a mishap or inclement weather,
or towing or transporting one via flatbed to a repair
shop or other location.
This vehicle is mainly used for road block removal , and its main
specialized devices are flat plates, supporting arms, winches, steel wire
ropes, and oil cylinders.
Product parameters
