6X4 Dongfeng 20m³ water truck
2024-10-09 15:48:19 Source：chusheng
6X4 Dongfeng 20m³ water truck
Chassis configuration:
1. Engine: D6.7NS6B320,Cummins 320hp
2.Transmission type: Fast 9-speed gearbox
3.Tyre:11.00R20, 10+1 spare
4.Wheelbase:4350+1350(mm)
5 Other: Electric glass, with original ABS, airbag seats, original air conditioning, central locking with remote key, driving recorder
Installation configuration:
1.The tank body is about 12 cbm.
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.
| Product Name |
6X4 Dongfeng 20m³ water truck |
| Driving type |
6X4 |
| Engine Model |
Cummins |
| Engine horsepower |
D6.7NS6B320 |
| Engine displacement |
6.7L |
| Gearbox |
Fast 9-speed gearbox |
| Tire specification |
11.00R20, 10+1 spare |
| Wheel base (mm) |
4350+1350(mm) |
| Gross vehicle weight(Kg) |
25000(kg) |
| Curb weight(Kg) |
13605,13670 (kg) |
| Rated weight(Kg) |
11200 (kg) |
| Vehicle dimensions (mm) |
10000X2550X3300(mm) |
| Tank volume(cbm) |
20 |
| Fuel type |
diesel |
| Emission standard |
Euro 6 (option:Euro3/4/5) |
| Water pump model |
40/50 |
| Tank material |
Q235 carbon steel,5mm |
| Additional configuration |
Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
6X4 Dongfeng 20m³ water truck
Water truck, also known as water sprinking truck,
multifunctional sprinkler truck, or garden greening sprinkler truck. Sprinkler
trucks are suitable for various road surface cleaning, tree, green belt, lawn
greening, road, factory and mining enterprise construction, and high-altitude
building cleaning. Sprinklers can also be used as water transport vehicles, and
the most common types of vehicles include sanitation sprinklers,
multifunctional sprinklers, and green sprinklers.
Parameters
