Foton Auman lightweight 12-14m³ mixer truck

Foton Auman lightweight 12-14m³ mixer truck

2024-10-07 09:54:11 Source：chusheng

Basic parameters of the vehicle:
Wheelbase: 1800+3050+1350mm, new Ouman ETX cab, Cummins 320 horsepower engine from the United States, 11 liter large displacement, HOWO 10 speed transmission, torque 1500, 11.00R20 steel wire tires, floating cab, 7.5-ton front axle, 16-ton Steyr rear axle, 320mm frame, airbag seats, electric doors and windows, air conditioning, reverse radar, driving record, brake self adjusting arm, adjustable headlights. The head is made of 8mm alloy steel wear-resistant material, and the tank body is made of 4mm high-strength wear-resistant material. Italian PMP gearbox, German Rexroth oil pump and motor, Kaipeng radiator, with pneumatic water supply device.

Product Name

Foton Auman lightweight 12-14m³ mixer truck

Driving Type

8X4

Total weight(kg)

31000(Kg)

Curb weight(kg)

14270(Kg)

Rated weight(kg)

16600(Kg)

Wheel base(mm)

1800+3050+1350(mm)

Overall Dimension(mm)

10300,9980×2550×3990(mm)

Tank maximum diameter(mm)

2100(mm)

Tank length(mm)

5800(mm)

Engine brand & model

Cummins 320 horsepower engine

Axle Quantity

Transmission Type

HOWO 10-speed gearbox

Steering Type

LHD or RHD with power steering

Tire Spec. & size

11.00R20 steel wire tire, 12+1 spare

Cab

Foton Auman cab

Tank material

Tank shell: 4mm Q345, tank head: 6mm Q345

Tank agitation capacity

7.6m³

Tank volume(m³)

12-14m³

Stadard configuration

The tank body is made of manganese steel Q345, 4mm material, and the head is made of 6mm high-strength steel Hydraulic system: Koyi reducer, Impop pump, motor.

Notice

The above information is for reference only, and vehicles can be customized depending on your requirements.

Foton Auman lightweight 12-14m³ mixer truck

A concrete mixer truck is a specialized truck used to transport concrete for construction purposes; Due to its appearance, it is often referred to as a snail car. These types of trucks are equipped with cylindrical mixing drums to transport the mixed concrete. During transportation, the mixing drum will always rotate to ensure that the concrete being transported does not solidify. After transporting the concrete, it is usually washed with water inside the mixing drum to prevent hardened concrete from occupying space and reducing the volume of the mixing drum.

Concrete mixer truckis also called cement mixer truck, cacapity range from 3 cbm to 16 cbm, chassis brand option: dongfeng, howo,shacman, foton, faw, isuzu, lveco, etc.
