Dongfeng KL 8X4 refrigerated truck

2024-10-07 09:54:11 Source：chusheng

Dongfeng KL 8X4 refrigerated truck

Chassis configuration:

1. Engine: DDi11E465-60,
2.Transmission type: Volvo Dongfeng 14 speed gearbox
3.Tyre: 12R22.5 vacuum tire, 12+1 spare
4.Wheelbase: 2050+4600+1350(mm)
5 Other: Fully floating cab suspension, hydraulic electric flip, airbag shock absorber driver

Installation configuration:

1-Box board material: The inner and outer wall panels are made of domestic 2.2mm fiberglass (which does not absorb light, has good thermal insulation, strong hardness, and is resistant to oxidation); The thickness of the trunk is 8CM.
The floor is made of aluminum patterned board, and the door edge strips are made of labyrinth rubber sealing strips.
2-Body accessories: aluminum alloy edging around the body, stainless steel corners, stainless steel door lock hinges, stainless steel door frames and hinges, energy-saving LED lighting inside the body.
3-Refrigeration unit: Kelly, Kexue, Lengwang, Carrier, Bayer and other refrigeration units can be optionally installed.
4-Optional configuration: movable frame meat hook, docking slide rail, ventilation groove, insulation plate, internal stainless steel, 380V backup power supply, ordinary tailboard or hydraulic tailboard.

Product Name

Dongfeng KL 8X4 refrigerated truck

Driving Type

8X4

Total weight(kg)

31000(Kg)

Curb weight(kg)

17770 ,16915(Kg)

Rated weight(kg)

13100,13890(Kg)

Wheel base(mm)

2050+4600+1350(mm)

Overall Dimension(mm)

12000X2600X3990(mm)

Cargo box size(mm)

9500,9400,9600X2440X2500(mm)

Engine brand & model

DDi11E465-60,

Displacement(L)/Power(kw)

10.8L/343KW

Axle Quantity

Transmission Type

Volvo Dongfeng 14 speed gearbox

Steering Type

LHD or RHD with power steering

Brake system

Air brake

Tire Spec. & size

12R22.5 vacuum tire, 12+1 spare

Cab

Fully floating cab suspension, hydraulic electric flip, airbag shock absorber driver

Cargo box configuration

The interior and exterior fabrics of the cabin are made of the latest nano glass fiber reinforced plastic (non light absorbing, good insulation, strong hardness, oxidation resistance), with a thickness of 8cm. The inner lining skeleton is made of rust resistant high-quality light steel profiles from WISCO, and the insulation material is filled with polyurethane foam without gaps. The bottom of the cabin is made of aluminum alloy patterned board or flat nano glass fiber reinforced plastic. The cabin is wrapped with galvanized stainless steel corners and thickened aluminum alloy edges. The rear door frame is made of stainless steel, and the thickened stainless steel rear door hinges and locks are used. LED lighting and cabin width lights are used inside the cabin.

Compartment structure

Do not open at the top, rear door opening, equipped with aluminum alloy ventilation slots on the floor, with stainless door frames and door accessory.

Refrigerated Unit

Customers can choose different units according to their vehicle needs, including -5 ℃, -10 ℃, -15 ℃, and -18 to -20 ℃ refrigeration units. Kelly, Kexue, Lengwang, Carrier, Bayer and other refrigeration units can be optionally installed.

Optional

The truck can be equipped with an optional Mobile frame style meat hook, docking slide rail, ventilation groove, insulation plate, inner stainless steel, 380V backup power supply, tailboard

Notice

The above information is for reference only, and vehicles can be customized depending on your requirements.

Dongfeng KL 8X4 refrigerated truck

Refrigerated truck is a closed van vehicle used to transport frozen or fresh goods. It is a specialized refrigerated transport vehicle equipped with a refrigeration unit and a polyurethane insulated compartment. It is commonly used to transport frozen food (refrigerated truck), dairy products (dairy transport truck), vegetables and fruits (fresh goods transport truck), vaccines and drugs (vaccine transport truck), etc.

Refrigerated truck consists of the walking part of a specialized vehicle chassis, as well as insulation and thermal insulation compartment (usually made of polyurethane material, fiberglass, color steel plate, stainless steel, etc.), refrigeration unit, temperature recorder inside the compartment, and other components. For vehicles with special requirements, such as meat hook trucks, optional accessories such as meat hooks, cargo blocking troughs, aluminum alloy guide rails, ventilation troughs, etc. can be added.
