JAC K5 obstacle clearing vehicle
2024-10-07 09:54:11 Source：chusheng
Chassis configuration:
JAC Weiling K5 cab, Yunnei YN25PLUS 1 engine (2.5-liter 143 horsepower), Wanliyang 8-speed all aluminum transmission, 3600mm wheelbase, rear wheelbase 1620mm, 180mm straight through three-layer beam, 6.5-ton rear axle, leaf spring 4/7+6, 700R16 steel wire tire, aluminum alloy fuel tank, central locking system, electric glass, multifunctional steering wheel, cruise control, factory air conditioning, T-BOX， Air brake off, electrically heated rearview mirror.
| Product Name |
JAC K5 obstacle clearing vehicle |
| Driving Type |
4X2 |
| Gross vehicle weight(Kg) |
4485(Kg) |
| Curb weight(Kg) |
2790,2855(Kg) |
| Rated weight(kg) |
1500(Kg) |
| Cab |
JAC Weiling K5 cab |
| Engine brand & model |
YN25PLUS1, Yunnei 143hp |
| Wheelbase(mm) |
3600(mm) |
| Axle Quantity |
2 |
| Transmission Type |
Wanliyang 8-speed all aluminum transmission |
| Steering Type |
LHD or RHD with power steering |
| Tire Spec. & size |
700R16 steel wire tire, (6+1) |
| Overall Dimension(mm) |
5995×2300×2250,2350,2415(mm) |
| Crane specification |
no crane (Crane can be installed) |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
JAC K5 obstacle clearing vehicle
Obstacle clearing vehicles, also known as road clearing vehicles, trailers, road rescue vehicles, and towing vehicles, have multiple functions such as lifting, pulling, and lifting. Obstacle clearing vehicles are mainly used for road malfunctioning vehicles, urban illegal vehicles, and emergency rescue.
Seven major advantages:
1.3600 wheelbase - no tilting head
2.2.5L 143 horsepower paired with 8-speed gearbox - Golden Power Chain
3.Rear axle weighing 6.5 tons - with stronger load-bearing capacity and lower maintenance costs
4.Strengthen the leaf spring by 4/7+6, which provides stronger load-bearing capacity
5.Aluminum alloy large fuel tank - longer range
6.Standard cruise control - more comfortable for long-distance driving
7.Original factory 180 straight through three story beam - no optimal load-bearing capacity
Product parameters
