Dongfeng heavy-duty pickup truck obstacle clearing vehicle
2024-10-07 09:54:11 Source：chusheng
Chassis configuration:
(1)Engine: M9T,120kw
(2)Wheelbase: 3400(mm)
(3)Transmission Type:8-speed gearbox
(4)Tire models: 255/60R18
(5)Other: Multi function steering wheel, the third mock examination driving (economic, sports, snow mode), electric air conditioning, tire pressure monitoring, reversing image, electric windows, remote keys, leather seats, electric rear-view mirrors, hydraulic struts
| Product Name |
Dongfeng heavy-duty pickup truck obstacle clearing vehicle |
| Driving Type |
/ |
| Gross vehicle weight(Kg) |
2500(Kg) |
| Curb weight(Kg) |
1885(Kg) |
| Rated weight(kg) |
/(Kg) |
| Cab |
Double row cab |
| Engine brand & model |
M9T,120kw |
| Wheelbase(mm) |
3400(mm) |
| Axle Quantity |
2 |
| Transmission Type |
8-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Tire Spec. & size |
255/60R18 |
| Overall Dimension(mm) |
5552,5602X1850.1900X1835,1875(mm) |
| Crane specification |
no crane (Crane can be installed) |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Dongfeng heavy-duty pickup truck obstacle clearing vehicle
Obstacle clearing vehicles,also known as road clearing vehicles, trailers, road rescue vehicles, and towing vehicles, have multiple functions such as lifting, pulling, and lifting. Obstacle clearing vehicles are mainly used for road malfunctioning vehicles, urban illegal vehicles, and emergency rescue.
Installation configuration:
A 3-ton articulated trailer with a split type cargo box, equipped with a front counterweight in the cab, reinforced plates on both sides of the support arm and hanging arm, 1 40KN winch (equipped with a 25 meter steel wire rope), 2 auxiliary carts, 1 pair of A-type auxiliary wheels (high-speed sports car), 2 special binding straps for the rear support arm, and a bent hook wrench for tightening the rope. Imported parts. Electro hydraulic valve, manual operation+wireless remote control.
Product parameters
