Mercedes Benz Auman 4X2 13m³/15m³ water truck
2024-10-09 15:48:19 Source：chusheng
Chassis configuration:
① The iconic 4-piece chrome plated diamond front face of the heavy-duty truck exudes a tough and domineering aura
② Optional Yuchai 200 horsepower, Yuchai 245 horsepower/6-cylinder engine, powerful
③ Fast 8-speed gearbox with synchronizer, smooth shifting and silky operation
④Mercedes Benz Ouman 2350mm wide body cab, airbag seats, comfortable driving experience
⑤ Equipped with original power take-off and power take-off switch
⑥250mm straight through double-layer beam, 10/10+8 reinforced and thickened leaf springs, 11 ton rear axle, strong bearing capacity
⑧Same volume, higher configuration, better performance, better price, great value for money, selling cars makes more money, buying cars saves more money
Standard configuration:air conditioning, multifunctional steering wheel, cruise control, airbag seats, ABS, dash cam, central locking system, electric glass, remote key, 10.00R20 steel wire tires
| Product Name |
Mercedes Benz Auman 4X2 13m³/15m³ water truck |
| Driving type |
4X2 |
| Engine horsepower |
Yuchai 220 hp/Yuchai 245 hp |
| Gearbox |
Fast 8-speed gearbox |
| Tire specification |
11.00R20, 6+1 spare |
| Wheel base (mm) |
3950/4500(mm) |
| Gross vehicle weight(Kg) |
18000(Kg) |
| Curb weight(Kg) |
7540,7290(Kg) |
| Rated weight(Kg) |
10330,10265,10580,10515(Kg) |
| Vehicle dimensions (mm) |
8585,8035,8005,7455×2510×3200,3100,2950,2900,2850(mm) |
| Tank volume(cbm) |
13m³/15m³ |
| Fuel type |
diesel |
| Emission standard |
Euro 6 (option:Euro3/4/5) |
| Water pump model |
40/50 |
| Tank material |
Q235 carbon steel,5mm |
| Additional configuration |
Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
Mercedes Benz Auman 4X2 13m³/15m³ water truck
Water truck, also known as water sprinking truck,
multifunctional sprinkler truck, or garden greening sprinkler truck. Sprinkler
trucks are suitable for various road surface cleaning, tree, green belt, lawn
greening, road, factory and mining enterprise construction, and high-altitude
building cleaning. Sprinklers can also be used as water transport vehicles, and
the most common types of vehicles include sanitation sprinklers,
multifunctional sprinklers, and green sprinklers.
Installation configuration:
1.The tank body is about 13m³/15m³
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.
Parameters
