6X4 Sinotruk Haoman 8m³ concrete mixer truck
2024-10-07 09:54:11 Source：chusheng
6X4 Sinotruk Haoman 8m³ concrete mixer truck
Chassis configuration:
Sinotruk Haoman 2080 white one and a half row cab, 6X4, wheelbase 3400+1350, 9-speed gearbox, Weichai 220 horsepower National VI with full power take-off, 5.5T front axle, 10T dual rear axle, 255mm double-layer beam, 10.00R20 steel wire tires.
Upper configuration:
Top configuration: imported hydraulic pumps and motors from Eaton, Sault, and Rexroth, Italian gearbox, and domestically produced 18L radiator. Standard configuration: The cylinder body is made of alloy steel QSTE500TM δ 4, the blades are made of alloy steel T510 δ 4 or the cylinder body is made of ultra-high strength plate 300TP δ 3.5, and the blades are made of alloy steel W800KC δ 3 (domestic lightweight heads use Q345 6mm).
Welcome to visit and inspect our factory!
| Product Name |
6X4 Sinotruk Haoman 8m³ concrete mixer truck |
| Driving Type |
6X4 |
| Total weight(kg) |
24500(Kg) |
| Curb weight(kg) |
10315(Kg) |
| Rated weight(kg) |
13990,14055(Kg) |
| Wheel base(mm) |
3400+1350(mm) |
| Overall Dimension(mm) |
8400×2420×3790(mm) |
| Tank maximum diameter(mm) |
2200(mm) |
| Tank length(mm) |
4600(mm) |
| Engine brand & model |
WP4.6NQ220E61A, Weichai 220hp |
| Displacement(L)/Power(kw) |
4.58L/162KW |
| Axle Quantity |
3 |
| Transmission Type |
9-speed gearbox |
| Steering Type |
LHD or RHD with power steering |
| Brake system |
Air brake |
| Tire Spec. & size |
10.00R20 steel wire tire, 10+1 spare |
| Cab |
Sinotruk Haoman 2080 white row and a half cab |
| Tank material |
Tank shell: 5 mm Q345, tank head: 6mm Q345 |
| Tank agitation capacity |
5.98m³ |
| Tank capacity |
8m³ |
| Stadard configuration |
The cylinder body is made of alloy steel QSTE500TM δ 4, the blades are made of alloy steel T510 δ 4 or the cylinder body is made of ultra-high strength plate 300TP δ 3.5, and the blades are made of alloy steel W800KC δ 3 (domestic lightweight heads use Q345 6mm). |
| Notice |
The above information is for reference only, and vehicles can be customized depending on your requirements. |
6X4 Sinotruk Haoman 8m³ concrete mixer truck
A
concrete mixer truck is a specialized truck used to transport concrete for
construction purposes; Due to its appearance, it is often referred to as a
snail car. These types of trucks are equipped with cylindrical mixing drums to
transport the mixed concrete. During transportation, the mixing drum will
always rotate to ensure that the concrete being transported does not solidify.
After transporting the concrete, it is usually washed with water inside the
mixing drum to prevent hardened concrete from occupying space and reducing the
volume of the mixing drum.
Concrete mixer truck is also called cement mixer truck, cacapity range from 3 cbm to 16 cbm, chassis brand option: dongfeng, howo,shacman, foton, faw, isuzu, lveco, etc.
Product parameters
