Heavy Truck HOWO flatbed transport vehicle: a flatbed truck suitable for transporting 150, 180, and 200 excavators with a single bridge.
Heavy duty truck HOWO TX luxury wide body cab, National VI Weichai 220 horsepower engine, HOWO 8-speed gearbox (with high and low gears), 7.5-ton front axle, 11.5-ton rear axle, 280 double-layer beam, tires: 295/60 vacuum tires, wheelbase: 5000, electrically flipped cab, original air conditioning, central door lock, electric glass, remote key, driving recorder, LED daytime running lights. The vehicle is equipped with a 9000X2550X3200mm excavator that can pull up to 20 tons.
We have many different brands and tonnages of flatbed trucks, please feel free to inquire.
| Product Name | Howo 4X2 flatbed transport vehicle, 20t excavator trailer |
| Chassis brand | Howo |
| Cab | Howo cab |
| Drive wheel | 4x2 |
| Steering wheel | Left/Right hand drive |
| Seat capacity | 2-3 person |
| Engine Model and displacement | WP4.6NQ220E61, 4.58L |
| Carframe | 280mm double layered beam |
| Wheel base | 5000(mm) |
| Front wheel track | 1950,2035(mm) |
| Rear wheel track | 1848,1860(mm) |
| Approach angle/departure angle | 19/11(°) |
| Front/rear suspension | 1430/2570(mm) |
| Axle numbers | 2 |
| F/R axle load | 5600/10400 |
| Tire sepcification and quantity | 295/60R22.5, 6 with 1 spare tire |
| Vehicle dimension | 9000X2550X3200(mm) |
| Flatbed dimension | 6250x2550x-(mm) |
| Gross vehicle weight(Kg) | 16000(Kg) |
| Curb weight(Kg) | 7970(Kg) |
| Rated weight(Kg) | 7900,7835(Kg) |
| Notice | The above information is for reference only, and vehicles can be customized depending on your requirements. |
Product Introduction
A flatbed transport vehicle, also known as a flatbed trailer, bulldozer transport vehicle, excavator transport vehicle, flatbed transport vehicle, hook machine transport vehicle, excavator flatbed truck, excavator trailer, excavator flatbed truck, hook machine flatbed truck, hook machine flatbed trailer, etc., is used to transport non removable machinery such as excavators, loaders, harvesters, etc.
