Dongfeng Huashen T3 6x2 flatbed truck

Dongfeng Huashen T3 6x2 flatbed truck

2024-09-18 10:36:10 Source：chusheng

Dongfeng Huashen T3 6X2 flatbed trailer, equipped with Weichai 220 horsepower engine, Fast 8-speed gearbox, 10 ton rear axle, 250 double decker beam, optional wheelbase of 1800+3800/4800mm, 10.00R steel wire tires, airbag seats, remote control center console, daytime running lights, sunshade, and driving recorder, with a total weight of 2450kg. It cannot be pulled by 150 excavators and is overweight. The overall size of the vehicle is 9860/10860X2550X3060mm

We have many different brands and tonnages of flatbed trucks, please feel free to inquire.

Product Name

Dongfeng Huashen T3 6x2 flatbed truck

Cab

Dongfeng Huashen T3 cab

Drive wheel

6x2

Steering wheel

Left/Right hand drive

Seat capacity

2-3 person

Engine Model and displacement

Weichai 220 horsepower, WP4.6NQ220E61A

Gearbox

Fast 8-speed with high and low gears

Carframe

250mm double layered beam

Wheel base

1800+3800,1800+4600mm

Axle numbers

Tire sepcification and quantity

10.00R20 18PR,295/60R22.5 18PR, 8+1 spare tire

Vehicle dimension

9860/10860X2550X3060mm

Flatbed dimension

5980,7450,8450x2550x-mm

Gross vehicle weight(Kg)

24500(Kg)

Curb weight(Kg)

9125,9500,9825(Kg)

Rated weight(Kg)

15180,14805,14480,15245,14870,14545(Kg)

Notice

The above information is for reference only, and vehicles can be customized depending on your requirements.

Dongfeng Huashen T3 6x2 flatbed truck

A flatbed transport vehicle, also known as a flatbed trailer, bulldozer transport vehicle, excavator transport vehicle, flatbed transport vehicle, hook machine transport vehicle, excavator flatbed truck, excavator trailer, excavator flatbed truck, hook machine flatbed truck, hook machine flatbed trailer, etc., is used to transport non removable machinery such as excavators, loaders, harvesters, etc.

Main Parameter
